PN8080,PN8081,AP8012,AP8022,PN8136,PN8137,PN8141,PN8143,PN8145,PN8147
內部集成了脈寬調制控制器和功率MOSFET，適用于小功率離線式開關電源。該芯片提供了完整的智能化保護功能，包括過流保護，欠壓保護，過壓保護，過溫保護和軟啟動功能。間歇工作模式能夠降低系統處于待機模式時的功耗...
產品描述：
AC-DC(SSR)
| Product | Character | SW Voltage | Standby Power | RDS(on) | Adaptor Output Power | Open Frame Output Power | Frequency | Package | VDD Operation Voltage |
|---|---|---|---|---|---|---|---|---|---|
| PN8080 | DC-DC converter | 200V | <150mW | 1.5Ω | 6W | 8W | 100KHz-1.5MHz | DFNWB4*4-8L/SOP8 | 7.6-16V |
| PN8081 | DC-DC converter | 200V | <150mW | 0.7Ω | 10W | 12W | 100KHz-1.5MHz | DFNWB4*4-8L SOP8 | 7.6-16V |
| AP8012H | PWM converter | 800V | <150mW | 25Ω | 6W | 8W | 45kHz | DIP8/SOP8 | 9~35V |
| AP8022H | PWM converter | 800V | <150mW | 14Ω | 10W | 12W | 60kHz | DIP8 | 9~35V |
| PN8136 | Low Standby-Power Off-line PWM converter | 800V | <30mW | 9.5Ω | 10W | 12W | 115kHz | SOP16 | 9~24V |
| PN8137 | Low Standby-Power Off-line PWM converter | 650V | <50mW | 6Ω | 15W | 18W | 60kHz | DIP7 | 9~24V |
| PN8141 | Low Standby-Power Off-line PWM Converter | 650V | <50mW | 3.6Ω | 12W | 18W | 100kHz | DIP7 | 9~29V |
| PN8143T | Low Standby-Power Off-line PWM Converter | 1000V | <50mW | 14Ω | 6W/8W | 6W/8W | 60kHz | SOP8/DIP7 | 9~24V |
| PN8145T | Low Standby-Power Off-line PWM converter | 1200V | <50mW | 12Ω | 8W | 10W | 60kHz | DIP7 | 9~24V |
| PN8147 | Low Standby-Power Off-line PWM converter | 650V | <50mW | 6Ω | 12W | 18W | 60kHz | DIP7 | 9~24V |
| PN8147H | Low Standby-Power Off-line PWM Converter | 800V | <50mW | 8Ω | 12W | 18W | 60kHz | DIP8 | 9~24V |
| PN8147T | Low Standby-Power Off-line PWM converter | 1100V | <50mW | 6Ω | 10W | 13W | 60kHz | DIP7 | 9~24V |
| PN8149 | Low Standby-Power Off-line PWM converter | 800V | <50mW | 4.6Ω | 24W | 28W | 125kHz | SOP12 | 9~23V |
| PN8150 | Low Standby-Power Off-line PWM Converter | 800V | <50mW | 1.6Ω | 28W | 35W | 125kHz | SOP12 | 9~23V |
| PN8149H | Low Standby-Power Off-line PWM Converter | 800V | <50mW | 2.5Ω | 18W | 30W | 60kHz | DIP8 | 9~24V |
| PN8149T | Low Standby-Power Off-line PWM Converter | 1100V | <50mW | 4Ω | 18W | 24W | 60kHz | DIP8 | 9~24V |
| PN8161 | Low Standby-Power Off-line PWM Converter | 690V | <50mW | 3Ω | 18W/24W | - | 125kHz(Max.) | DIP8/SOP8 | 10~38V |
| PN8162 | Low Standby-Power Off-line PWM Converter | 690V | <50mW | 3Ω | 25W/30W | - | 125kHz(Max.) | PDFN5*6/SOP12 | 10~38V |
| PN8165 | Low Standby-Power Off-line PWM Converter | 650V | <50mW | 0.5Ω | 36W | - | 125kHz(Max.) | PDFN5*6 SOP8 | 10~38V |
| PN8166 | Low Standby-Power Off-line PWM Converter | 650V | <50mW | 0.6Ω/0.3Ω | 36W /45W | - | 125kHz(Max.) | SSOP10 | 9~57V |
| PN6661H | Low Standby-Power Off-line PWM Converter | 800V | <50mW | 2.5Ω | 18W | 30W | 60kHz | DIP7 | 9~24V |
| PN8173 | AC/DC Converter with Internal Self-Supply Circuit | 800V | <50mW | 14Ω | 5W | 5W | 124kHz | SOP7 DIP7 | 10~18V |
| PN8175 | AC/DC Converter with Internal Self-Supply Circuit | 800V | <50mW | 5Ω | 8W | 8W | 124kHz | SOP7 DIP7 | 10~18V |
| PN8177 | AC/DC Converter with Internal Self-Supply Circuit | 800V | <50mW | 2.5Ω | 10W | 10W | 124kHz | DIP7 | 10~18V |
| PN8775P | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 19Ω | 6W | 8W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8776 | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 13Ω | 7W | 9W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8777 | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 6.4Ω | 8W | 10W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8778 | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 4.6Ω | 10W | 12W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8779 | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 3.7Ω | 12W | 15W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8770 | AC/DC Converter with Internal Self-Supply Circuit | 750V | <50mW | 2Ω | 15W | 20W | 124kHz | DIP7/SOP7/SMP7 | 5.6~7V |
| PN8192C | AC/DC Converter with Internal Self-Supply Circuit | 800V | <100mW | 22Ω | 4.5W | 5.5W | 124kHz | DIP7 | 5~7V |
| PN8700 | High performance Multi-mode AC-DC Controller | 1700V | <75mW | 1.0Ω | 36W | 45W | 85kHz | DIP7 | 9~37V |
| PN8712H | Fixed Frequency Multi-mode AC-DC Controller | 800V | <50mW | 2.8Ω | 15W | 20W | 125kHz 100kHz 60kHz | DIP7 | 11~24V |
| PN8715H | Fixed Frequency Multi-mode AC-DC Controller | 800V | <50mW | 0.5Ω | 40W | 42W | 125kHz 100kHz 60kHz | SOP12/DIP7 | 11~24V |
| PN8732 | AC/DC Converter with Internal Self-Supply Circuit | 800V | <100mW | 2.8Ω | 15W | 20W | 100kHz | DIP7 | 5~7V |
| PN8733 | AC/DC Converter with Internal Self-Supply Circuit | 800V | <100mW | 4Ω | 18W | 24W | 100kHz | DIP7V SMP7 | 10~29V |
| PN8783 | PWM Converter | 650V | <55mW | 0.165Ω | 65W | 90W | 500kHz(Max.) | QFN6*8 | 8V~58V |
| Product | Character | StandbyPower | Start-up Current | VDD Operation Voltage | Vcc_Clamp | OutputPower | Frequency | Package | Note |
|---|---|---|---|---|---|---|---|---|---|
| AP8262 | PWM Controller | <500mW | 200uA | 7.6~34V | 40V | <100W | 500kHz(Max.) | SOP8 | |
| AP8260Q | PWM Controller | <0.2mW | 1.5mA | 3.5V~40V | - | <1A | 100kHz~1MHz | SOP8&MSOP8 | xx3478 |
| AP8262C | PWM Controller | <500mW | 200uA | 7.6~34V | 40V | <100W | 500kHz(Max.) | SOP8 | xxx28C42/3/4/5 |
| AP8265 | PWM Controller | <100mW | 4uA | 8.5~26V | 40V | <200W | 200kHz(Max.) | SOP8 | |
| AP8267 | PWM Controller | <100mW | 2uA | 8~26V | 27V | <70W | 65kHz | SOT23-6 | - |
| AP8268 | ?PWM Controller | ?<75mW | ?2uA | ?10~26V | 30V | ?<70W | ?65kHz | ?SOT23-6 | - |
| AP8270 | ??PWM Controller | ????<100mW? | 4uA | ?10~26V? | ?28V? | ?<70W? | ?????100kHz | SOT23-6 | - |
| AP8271 | PWM Controller | <100mW | 4uA | 7.5-26V | 28.5V | <100W | 100Khz | SOT23-6 | - |
| PN8272 | PWM Controller | <50mW | ﹣3mA | 9~35V | 40V | <120W | 65kHz | SOP7 | HV Start-up |
| PN8273 | ??PWM Controller | ????<50mW? | ﹣1.5mA | ?10~40V? | ?40V? | ?<120W? | ?????65kHz | SOP7 | HV Start-up |
| PN8275 | ??PWM Controller | ????<50mW? | ﹣1.5mA | ?10~40V? | ?40V? | ?<120W? | ?????65kHz | SOP7 | HV Start-up |
| PN8211 | PWM Controller | <50mW | ﹣1.4mA | 8~57V | 60V | <200W | 110kHz | SOP7 | |
| PN8212 | PWM Controller | <50mW | ﹣1.0mA | 9~57V | 60V | 65W | 200kHz(Max.) | SOP7 | HV Start-up |
| PN8213 | PWM Controller | <50mW | ﹣3mA | 9~56V | 60V | <150W | 500kHz(Max.) | SSOP10 |
